Product Code: AKN-JDA
Tank Volume | 8 m³ - 12 m³ |
Vacuum Pump | Blower, up to 9.000 m³/h (free air) |
Air Compressor | 1.5 m³/min, 8 bar |
Filtration | Automatic |
Suction Boom | 8" Folding Arm Boom |
Pump Drive | NMW or Split PTO |
Control | Control panel, automation, wireless or HMI |
Sound Isolation | Optional – Sound isolation |
Telescobic Lifting | Up to 55 degrees |
J-DA is the solution for vacuum loading and pneumatic transport of hazardous dusts, sludges and liquids. Thanks to its high suction power, it guarantees extraordinary results, even in extreme working conditions.
J-DA can also mount a vast range of vacuum pumps with flow rates of from 6,500 m3/h to 9,000 m3/h with a maximum vacuum of 93%. The special filter housing incorporated in the tank guarantees perfect suction efficiency and extends the working life of the filter bags, while the cover with hydraulic opening and closing simplifies maintenance. The exclusive automatic system for self-discharging the dust from the filter housing into the tank maintains a continuous flow without having to interrupt suction, thus eliminating down time.
The exclusive Venturi pneumatic pressure offloading system enables the dust to be offloaded at a height of up to 60 m.
