Product Code: AKN-SPS-UUR
Product Code | AKN-SPS-UUR2400 | AKN-SPS-UUR3005 |
Exit-1 | Flange | Flange |
Exit-2 | Flange | x |
Position | Horizontal | Vertical |
Hydraulic Exit | ISO | ISO |
Pneumatic Control | Yes | Yes |
Weight | 195 kg | 250 kg |
Oil Type | ATF | ATF |
Ratio | 1,3 | 1-1,25 |
POWER TAKE-OFF & SPLIT SHAFT PTO
DOUBLE OUTPUT SPLIT SHAFT - UUR2400 PRODUCT CODE: AKN-SPS-U24
SINGLE OUTPUT SPLIT SHAFT - UUR3000 PRODUCT CODE: AKN-SPS-U30
This Split Shaft PTO is mounted to the Trucks’ drive shaft to give the power to the desired equipment. UUR 2400 is automatic split shaft PTO. Automatic PTO oil ATF should be used. The transition is done by steel and bronze discs to guarantee this process separately by one or two applications. The Vehicle drive shaft should be at rest when the outputs are engaged or disengaged. The below values would be guaranteed, if the right split shaft mounted to the appropriate vehicle.
